TRG-300 Tiger

TRG-300 Tiger

The TRG-300 Tiger (also known as TRG-300 Kasirga) multiple launch rocket system (MLRS) system is a modern missile launching system developed for the Turkish Armed Forces. It is manufactured by Turkish weapons manufacturer and defense contractor Roketsan.

The system has four 300 mm rocket launcher tubes and its rockets can hit a maximum range of 120 km.

The system can fire the TRG-300 Tiger missile, which comes in two different variants block I & block II

Block I

Block I  has greater  range with a smaller warhead than Block II:

• Range: 30–120 km
• Weight: 585 kg
• Warhead weight: 105 kg
• Warhead effective radius: ≥ 70 m

Block II

Block II  has a enhanced warhead dynamic effected:

• Range: 20–90 km
• Weight: 670 kg
• Warhead weight: 190 kg
• Warhead effective radius: ≥ 80 m

According to Roketsan, guidance for both TRG-300 variants is provided by GPS and aided by an inertial navigation system. Both missiles feature aerodynamic control with an electromechanical actuation system.

TIGER Missile can be launched from the RoketsanTigerMulti Barrel Rocket Launcher (MBRL) Weapon System, MCL (Multi-Caliber Launcher) Weapon System, and other platforms with compatible interfaces.

Potential Targets

• Targets Located with High Accuracy
• Artillery and Air Defence Systems
• Radar Sites
• Assembly Areas
• Logistic Facilities
• C3 Facilities
• Other High Priority Targets

System Specifications

• Combat Proven
• 7/24 All-Weather/Terrain Usage Capability
• Ready to Fire
• Low Collateral Damage
• Long Range Highly Accurate Precision Strike Capability
• Anti Jamming/Anti Spoofing Solutions

Technical Specifications of TRG-300 MBRL

• Diameter :          300 mm
• Weight             585 kg for block I, 670 kg for block II
• Guidance     Global Positioning System + Global Navigation Satellite System Aided                                  Inertial Navigation System
• Control:             Aerodynamic Control with Electromechanical Actuation System
• Propellant Type: Composite Solid
• Warhead Types : High Explosive + Steel Ball
• Warhead Weight: 105 kg 190 kg
• Warhead:
• Effective Radius: ≥ 70 m ≥ 80 m

• Fuze Type:         Point Detonating and Proximity
• Accuracy (CEP): ≤ 10 m
